The PIC16F721T-I/SS and PIC16F721-I/SS are high-performance 8-bit microcontrollers (MCUs) launched by Microchip, featuring a compact 20-pin SSOP package that balances space-efficient design with functional integration. Powered by a 16 MHz core frequency and equipped with 7 KB of Flash memory, they support rapid data processing and flexible program storage, making them suitable for applications requiring real-time responsiveness. Their standout advantage lies in ultra-low power design, incorporating nanoWatt XLP™ technology to achieve a sleep-mode current as low as 50 nA (typical at 1.8 V). Combined with multi-mode power management (e.g., DOZE/IDLE), these MCUs significantly extend battery life in portable medical devices, wireless sensor nodes, and similar applications.

Functionally, the series integrates a 12-bit high-precision ADC (on select models), enabling multi-channel analog signal acquisition for high-accuracy requirements such as environmental monitoring and pressure sensing. It includes three 16-bit timers and a hardware PWM module for precise motor speed control or LED dimming. The communication interfaces are extensive, covering EUSART, I²C, and SPI, supporting RS-485 industrial bus or sensor network connectivity. Additionally, the PIC16F721T-I/SS is AEC-Q100 certified, operating within a temperature range of -40°C to 125°C to meet the stringent environmental demands of automotive electronics. The standard PIC16F721-I/SS covers an industrial temperature range of -40°C to 85°C, suitable for automation control, smart home applications, and other scenarios. With their low power consumption, high integration, and reliability, these series represent an ideal choice for cost-sensitive industrial and consumer electronics applications.

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

Microchip PIC16F721-I/SS | 20-Pin SSOP MCU, 12-Bit ADC, 3 Timers, EUSART/I2C/SPI Interfaces, Industrial Temp Range (-40°C~85°C)

Key Product Advantages

Ultra-Low Power Consumption
- nanoWatt XLP™ Technology: Sleep mode current as low as 50nA (typical at 1.8V), with active current of just 50μA/MHz, significantly extending battery life for portable devices.
- Wide Voltage Operation: Supports 1.8V~5.5V (PIC16F721-I/SS) or 1.8V~3.6V (PIC16F721T-I/SS), accommodating diverse power supply scenarios.
High Performance & Integration
- 16MHz Clock Speed: Paired with 7KB Flash and 256B SRAM, enabling rapid data processing.
- 12-Bit ADC (Select Models): Delivers high-precision analog signal acquisition (e.g., temperature, pressure sensing), outperforming standard 10-bit ADCs in competing 8-bit MCUs.
- Multi-Communication Interfaces: Integrated EUSART, I2C, and SPI, supporting RS-485 industrial buses or sensor network connectivity.
Reliability & Flexibility
- Industrial-Grade Temperature Range: PIC16F721-I/SS operates from -40°C to 85°C, while PIC16F721T-I/SS (automotive-grade) supports -40°C to 125°C, ideal for harsh environments.
- Hardware Security: Features code protection and a watchdog timer (WDT) to prevent program errors or data breaches.

Typical Application Scenarios

Industrial Automation
- Sensor Data Acquisition: Leverage the 12-bit ADC and multi-channel inputs for real-time monitoring of temperature, humidity, or pressure, with data transmitted via EUSART/I2C to a master controller.
- Motor Control: Utilize PWM modules and timers for precise speed regulation of stepper or DC motors (e.g., valve control, conveyor systems).
Automotive Electronics
- Body Control Module (BCM): Manage low-complexity actuators like windows, wipers, or lights, with LIN bus support via EUSART.
- Battery Management System (BMS): Monitor battery voltage and temperature, extending EV range through ultra-low power design.
Consumer Electronics
- Portable Medical Devices: Enable months-long battery life in digital thermometers or glucose meters using XLP mode.
- Smart Wearables: Drive heart rate sensors or LED displays while minimizing PCB footprint with the SSOP-20 package.
Smart Home
- Environmental Monitoring Nodes: Integrate temperature/humidity sensors and Wi-Fi modules, transmitting data via I2C.
- Security Systems: Detect door/window status using comparator modules and trigger alarms in low-power standby mode.
Internet of Things (IoT)
- Wireless Sensor Networks: Combine low-power operation with ADC for remote monitoring of soil moisture or light intensity.
- Smart Agriculture: Control irrigation valves via PWM and timers for automated watering schedules.
