Metal Core PCBs (MCPCBs)
Explore metal core pcbs (mcpcbs) requirements and review related PCB manufacturing and assembly capabilities.
PRODUCT GALLERY
Click an image to viewProduct & manufacturing images
Reference images illustrate related products and processes. Your supplied design, model and configuration will be confirmed for your project.
Detailed Technical Parameters
Comprehensive technical specifications to meet various application needs from consumer electronics to aerospace
| Project | Standard capabilities | Advanced abilities | Remark |
|---|---|---|---|
| Standard FR4 | ITEQ IT-180, KB-6167, Shengyi S1141 | Tg 140°C, Low Z-axis expansion | Consumer electronics, Industrial control |
| High Tg FR4 | Isola 370HR, Panasonic R-1755V, Shengyi S1000-2 | Tg 170-180°C, Halogen-free | Automotive electronics, Power products |
| High Frequency Material | Rogers RO4350B, Taconic RF-35, Shengyi SY-T880 | Dk 3.48, Low loss | 5G communication, Radar systems |
| High Speed Material | Isola I-Speed, Panasonic Megtron 6, Shengyi SY-8820 | Low Dk/Df, Signal integrity | Servers, High-speed networks |
| Metal Substrate | Aluminum/Copper based, Bergquist MP, Shengyi SY-M300 | Thermal conductivity 1-3W/mK | LED lighting, Power modules |
| Flexible Material | DuPont Pyralux, Panasonic R-F775, Shengyi SY-F200 | Polyimide substrate, High flexibility | Wearable devices, Foldable screens |
| Rigid-Flex Material | DuPont Pyralux AP/AC, Shengyi SY-RF600 | Multi-layer rigid-flex structure | Medical equipment, Aerospace |
| Ceramic Substrate | Alumina/Aluminum nitride, Shengyi SY-C500 | High thermal conductivity, High reliability | High-power LED, Lasers |
