Capacity

High-Frequency &High-Speed PCBs

Explore high-frequency &high-speed pcbs requirements and review related PCB manufacturing and assembly capabilities.

PRODUCT GALLERY
Click an image to view
high-frequency & high-speed PCB manufacturing
high-frequency & high-speed PCB manufacturingFull-size image

Reference images illustrate related products and processes. Your supplied design, model and configuration will be confirmed for your project.

Detailed Technical Parameters

Comprehensive technical specifications to meet various application needs from consumer electronics to aerospace

ProjectStandard capabilitiesAdvanced abilitiesRemark
Standard FR4ITEQ IT-180, KB-6167, Shengyi S1141Tg 140°C, Low Z-axis expansionConsumer electronics, Industrial control
High Tg FR4Isola 370HR, Panasonic R-1755V, Shengyi S1000-2Tg 170-180°C, Halogen-freeAutomotive electronics, Power products
High Frequency MaterialRogers RO4350B, Taconic RF-35, Shengyi SY-T880Dk 3.48, Low loss5G communication, Radar systems
High Speed MaterialIsola I-Speed, Panasonic Megtron 6, Shengyi SY-8820Low Dk/Df, Signal integrityServers, High-speed networks
Metal SubstrateAluminum/Copper based, Bergquist MP, Shengyi SY-M300Thermal conductivity 1-3W/mKLED lighting, Power modules
Flexible MaterialDuPont Pyralux, Panasonic R-F775, Shengyi SY-F200Polyimide substrate, High flexibilityWearable devices, Foldable screens
Rigid-Flex MaterialDuPont Pyralux AP/AC, Shengyi SY-RF600Multi-layer rigid-flex structureMedical equipment, Aerospace
Ceramic SubstrateAlumina/Aluminum nitride, Shengyi SY-C500High thermal conductivity, High reliabilityHigh-power LED, Lasers
GETTING STARTED

Information to include with your request

Providing the available details below helps the team understand what you need. Only share information you are authorized to provide.

  • The capability area you would like to discuss
  • Relevant design or production files, where available
  • Target quantity, schedule, and quality expectations
  • Your contact details for a manufacturing review
