High-Density SMT Assembly
Explore high-density smt assembly requirements and review related PCB manufacturing and assembly capabilities.
PRODUCT GALLERY
Click an image to viewProduct & manufacturing images
Reference images illustrate related products and processes. Your supplied design, model and configuration will be confirmed for your project.
Detailed Technical Parameters
Comprehensive technical specifications to meet various application needs from consumer electronics to aerospace
| Project | Standard capabilities | Advanced abilities | Remark |
|---|---|---|---|
| Component type | 0201, 0.4mm QFP | 01005, 0.2mm BGA/QFN | Supports special-shaped components |
| Placement accuracy | ±25μm @ 3σ | ±15μm @ 3σ | Fuji NXT III platform |
| Solder paste printing | ±15μm repeat accuracy | ±10μm repeat accuracy | DEK Horizon printer |
| Reflow soldering | 8-zone lead-free reflow oven | 10-zone nitrogen protection | Precise temperature profile control |
| Inspection capability | 2D AOI, ICT | 3D AXI, FCT, flying probe test | Full-process quality control |
| Soldering standard | IPC-A-610 Class 2 | IPC-A-610 Class 3 | Military/Medical grade standard |
| Cleaning process | Aqueous cleaning | Plasma cleaning | High reliability requirements |
| Conformal coating | Acrylic coating | Polyurethane/Silicone coating | Selective coating process |
