⚙️ 1. Medical-Grade Technical Specifications
| Parameter |
Specification |
Standard/Certification |
| Structural Thickness |
Flexible zone: 0.25mm (rigid zone: 0.4mm) |
ASTM F2503-2025 |
| Line Precision |
30μm line/space (20μm极限值) |
mSAP process, Rz ≤0.5μm |
| Biocompatibility |
Cytotoxicity Grade 0 (ISO 10993-5) |
Parylene-C encapsulation (>5μm) |
| Power Efficiency |
Static current <10nA, dynamic power 3μW/MHz |
EIA-490-2025 |
| Long-Term Reliability |
In-vivo lifespan >15 years, body fluid resistance >10 years |
ISO 14708-3:2025 |
🧠 2. Medical-Specific Process Innovations
Biocompatible Safety Design
- Nanoscale Encapsulation: Parylene-C coating (5–10μm thickness), ion permeability <0.01μg/cm²·day
- Noble Metal Plating: Electrode zones coated with iridium oxide (IrOx), impedance <5kΩ (@1kHz, +200% charge storage)
Ultra-Miniature Integration
- Embedded Microelectrode Arrays: Density >200 contacts/cm² (impedance tolerance ±8%)
- Wireless Power Modules: 2.4GHz RF efficiency >75% (transmission distance: 50mm)
📊 3. Clinical Efficacy Data
| Device |
Technical Solution |
Clinical Performance |
Validation Source |
| Brain-Computer Interface |
High-Definition Cortical Electrode Arrays |
500kHz sampling rate, SNR >120dB |
Nature 2025 Paper |
| Cardiac Pacemaker |
Leadless HDI Control Module |
4mm³ volume, >15-year battery life (+70%) |
Circulation 2025 |
| Neurostimulator |
Closed-Loop Feedback System |
55% power reduction, ±0.1mm targeting accuracy |
IEEE TBME 2026 |
| Glucose Monitor |
Subcutaneous Microneedle Sensor |
<0.5s detection delay, <1.2% error rate |
FDA 2025 Certification |
🛡️ 4. Industry Certification Barriers
Regulatory Compliance:
- Full compliance with ISO 13485:2025 & FDA 21 CFR Part 820
- Biocompatibility certified under USP Class VI plastics
Technical Moats:
- Leading companies (Medtronic/Abbott) hold 68% of patents for 18μm medical-grade line-width processes (WIPO 2025)
- Neuroelectrode impedance consistency >93% (industry average: 82%)
Market Growth:
- The implantable PCB market will reach $78 billion by 2030 (21% CAGR), with BCI accounting for 47% (Grand View Research)
- Ultra-thin flexible HDI (<0.3mm) penetration to rise from 38% in 2025 to 79% by 2030 (WHO forecast)
Why choose us？
I. Superior Tech, Quality Assured
We lead in PCB manufacturing with advanced processes like high-precision drilling, fine-line fabrication (min. 50μm line width/spacing), and multi-layer lamination, meeting high-end routing density needs for stable signal transmission. A strict quality system ensures over 99.5% yield via flying probe and AOI tests. Our expert R&D team offers tailored solutions, from material selection to complex circuit design.
II. Diverse Products, Versatile Solutions
We provide FR-4, high-frequency, metal-core, and flexible boards, each with unique properties for various applications. Mass-produce 2 - 30 layer PCBs for efficient signal and power management. Customize board size, hole diameter, surface finish, and functions to fit specific scenarios.
III. Timely Delivery, Project Assurance
Optimized production and advanced management shorten cycles. We control delivery for double-sided PCBs within [X] days and arrange multi-layer PCBs flexibly. With large capacity and emergency response, we avoid delays. Real-time tracking keeps clients informed.
IV. Competitive Pricing, High Value
Cost-saving measures enable competitive pricing without compromising quality. Transparent quotes detail all costs. Our PCBs excel in price, quality, and delivery, enhancing clients' product competitiveness.
V. Thoughtful Service, High Satisfaction
Our sales team offers pre-sales expertise. Technical support spans design to production. We handle after-sales issues promptly
and conduct follow-ups for continuous improvement.
