I. Core Performance Parameters (Industry Benchmark Comparison)
| Metric |
Technical Specifications |
Competitive Gap |
| Memory Channels |
Dual-channel DDR5-7200 (115GB/s bandwidth) |
Supports 1 DPC R-DIMM ⭐ |
| PCIe Expansion |
PCIe 6.0 x16 (256GT/s) |
Signal loss <4dB @25GHz |
| PCB Layers |
24-layer AnyLayer HDI |
Trace width/spacing 40μm |
| Thermal Management |
3D vapor chamber + liquid cooling (0.1℃/W Rth) |
65% lower temp vs. traditional cooling |
| Power Density |
12W/cm² (@TDP 350W) |
80 PLUS Titanium certified |
Data Insight: IDC Q2 2025 reports the global server motherboard market at $24.8B, with liquid cooling penetration reaching 40% and PCIe 6.0 demand growing 52% annually.
II. Material & Process Innovations
High-Speed Material Solutions:
- Panasonic MEGTRON 7 (Dk=3.3, Df=0.001 @16GHz) – Ensures PCIe 6.0 signal integrity
- Embedded decoupling capacitors (ZBC2000) – Reduces power supply ripple by 45%
- Domestic alternative: Shengyi Synamic 6EX (28% cost reduction, certified by Inspur/Sugon)
Signal Integrity Processes:
|
|
graph LR |
|
|
A[Backdrill stub ≤8mil] --> B[Differential pair length tolerance ±0.08mm] |
|
|
B --> C[Hybrid laser drilling ±12μm] |
|
|
C --> D[32-channel TDR testing] |
III. Mass Production Cost & Delivery (2025 Pricing)
| Service Type |
Technical Specifications |
Price |
Lead Time |
| 16-layer prototype (5 pcs) |
Dual-channel DDR5 + 4x PCIe 6.0 |
$450/board |
48 hours |
| 20-layer mid-volume (1K pcs) |
Liquid-cooled substrate + 8x power planes |
$175/unit |
15 days |
| 24-layer enterprise (10K pcs) |
Wide-temp (−40℃~+105℃) military-grade强化 |
$210/unit |
25 days |
⚠️ Industry Pain Point: TechInsights 2025 highlights that 23% of server failures stem from PCB signal interference. This solution reduces risk to 0.8% via ANSYS HFSS simulation optimization.
IV. Reliability Verification System
Environmental Testing:
- 2,000 thermal cycles (−55℃↔125℃) – Copper foil peel strength maintained >1.2N/mm
- 1,500-hour 85℃/85%RH aging – Insulation resistance >10⁹Ω
Electromagnetic Compatibility:
- Radiated noise <28dBμV/m (exceeds FCC Class A limits)
- ESD protection ±20kV (IEC 61000-4-2 Level 4)
